Brustor B-150XL

Brustor-B-150XL

Important !
Each L-side must have at least 1 drainage.

Features and benefits
– highly aesthetical, aluminum construction with 6” louvers
– regulable sun shading system with 150° adjustable louvers
– maximum dimensions: 19’10” long x 11’6” wide x 9’10” high
– natural cooling by adjusting the angle of the louvers
– rectangular profiles with built-in water drainage
– windproof up to 103 miles/h with open or closed louvers
– standard with 4 posts and integrated pole supports
– modules can be coupled along the length, not along the width
– water drainage: 2 non-coupled rain gutters along the L-side
– lean-to version > 49 sq. ft. or along the L-side: wall post is needed
– lean-to version: watertightness of the space between the wall and the pergola is the installers responsibility

PRODUCT SPECIFICATIONS
Transmitters and Sensors Standard Operation Louvers: Somfy Altus RTS Motor and Telis 1 Module with LED Lighting, Heater(s): Telis 4 (included)
Heaters and Other Options Standard Telis 1 RTS(Telis 4 with White LEDs, Heaters)
Standard Colors Brustor White Texture, Anthracite Grey 7016 Texture
