Brustor B-500

Brustor-B-500

Important !
Each roof element + every 49 sq.ft. has to have at least 1 drainage The electric box can also be installed in the frame if no screens are present.

Features and benefits
– highly aesthetical, aluminum construction with sliding cover
– available as stand-alone or lean-to version
– motorized sliding cover with Somfy RTS motor(s)
– waterproof beige, grey or white black-out PVC fabric (23 oz)
– maximum dimensions: 23’ long x 23’ wide x 9’8” high
– modules can only be coupled along the width
– wind class 3 (6 Beaufort) with opened sliding cover
– standard with 4 posts and integrated pole supports
– water drainage with 4 coupled rain gutters
– protection cover as protection for folded fabric
– extra height roof construction above posts: 5.5”
– lean-to version: watertightness of the space between the wall and the pergola is the installers responsibility

PRODUCT SPECIFICATIONS
Transmitters and Sensors Standard Operation Folding Cover: Somfy Altus RTS Motor(s) and Telis 1
Heaters and Other Options Telis 4 with Screens(2), 2 Roof Elements, LEDs, Heater(s)
Standard Colors Brustor White Texture, Anthracite Grey 7016 Texture
