The SecureZip Max from Stobag is a robust zipper system that is ideal for larger widths and high wind applications The unit is housed in a 6 ” X 6 ” two-part aluminum box that is slightly rounded with a plastic brush to dampen emerging noise.
The cast aluminum alloy end caps complete the box and lock the two parts together. The roller tube is a 4” galvanized steel that is driven by a Somfy Tubular motor.
The two-piece track simplifies installation and utilizes a patented spring system that allows the unit to absorb significant wind loads, and provide all the additional benefits associated with zipper systems.
| PRODUCT SPECIFICATIONS | |
|---|---|
| Linear Width | 3'5" - 23' |
| Projection | 3' - 19' |
| Frame Finish | Polyester Powder Coated |
| Frame Colors | White |
| Mounting Options | Wall, Soffit | Roller Tube | 4" Steel | Box Size | Width: 6-1/2" | Height: 6-1/2" |
| Fabric Guidance | Side Tracks with Zipper Retension |
| Fabric Protection | 6.5" Extruded Aluminum Box |
| Mode of Operation | Somfy Tubular Motor |
| Fabric Options | Variable Openness Screen, Opaque, Blackout |
